NP-08EHP PDU provides intelligent remote power management operations, allowed by diversified ways to access and control including network protocols and local etc control mode, multistage system administrative privileges, network security account can be simple, rapid and reliable implementation of the power control，parameter monitoring and status of the equipment real-time detection.
|
Features |
l One RS232 console port & one 10M/100M-T RJ45 Ethernet port, support
AUTO-MDIX. l One sensor port and three digital display
tube to display
temperature and humidity. l Support
Electric energy parameters l Support
DHCP or static
IP configure l Integrated SNMP agent and Trap notification message capability l POP3/SMTP for sending and receiving control
commands or user data l Support password protecting user
management，8 user at most, and the port
owner and access permission could be set l Support 8 ports control，and could be customized l Support
port
name,
power on status and owner setting l User’s software upgrading
is available |
|
Functions |
l Web,Telnet,RS232,SNMP,Email management access l Local and remote temperature/humidity/current checking and display. l Current alarm threshold by locale, email, trap methods l Event timers/clock for each
power outlet. l Switch and reboot each outlets l Port reservation for different permissions. l Auto-ping for each power outlet by ICMP ping package, and can be reboot. l Simple internet firewall, forbid remote access
illegally l Each Outlets current, voltage, power, power factor,
electric energy |
|
Electrical parameter |
|
|
Enter Plug |
1/2 |
|
Supply Plug |
CEE7/7 |
|
Equipment end |
IEC60320-C14 |
|
Outlets |
(8) IEC60320-C13 |
|
Input Current |
20 Amp |
|
Input Voltage |
230 VAC |
|
Console Port |
Baud rate:115200; 8 data bits ; No parity;1 stop bit, no hardware handshaking |
|
Ethernet |
10/100 Base-T, support
AUTO-MDIX |
|
Network Protocol |
ICMP, IP, TCP/UDP, DHCP, Telnet, DNS, POP3/SMTP, SNMP, HTTP |
|
Display |
22 LEDs |
|
Other parameter |
|
|
Chassis |
W: 19＂ (482mm) |
|
D: 9.67＂ (245mm) |
|
|
H: 1.75＂ (44mm) |
|
|
Operating Temperature |
0°C – 50°C |
|
Storage Temperature |
-29°C – 60°C |
|
Humidity |
10-90% RH |
